QSFP28 Pluggable EDFA Preamplifier for DWDM, Duplex LC, Input power -30dBm to -10dBm, Nominal gain +17dB
SKU: ADD-QSFP28-EDFA-PREAMP-17DB
United Kingdom: 0 in stock
North America: 0 in stock
Available from the following dealers:
This QSFP28 pluggable EDFA preamplifier offers a optical input range and provides a +17dB nominal gain to a C-Band DWDM link. The pluggable EDFA connects to a composite DWDM link via an LC connector. It is configured for Automatic Gain Control (AGC) by default and can be further configured via CLI prompt in supported hosts or by our coding and tuning system.
Technical Specification
| Connector 2 | LC |
| Connector 1 Gender | Male |
| Compatible OEM | Industry Standard |
| Connector 1 | QSFP28 |
| Connector 2 Gender | Female |
| Network | DWDM |
| Input Power | -30dBm to -10dBm |
| Nominal Gain | +17dB |
Physical Specification
| Product Shipping Dimension(HxWxD) | 22 in. x 17 in. x 12 in. |
| Product Shipping Weight(LB) | 7.8 |
Miscellaneous
| Country Of Origin | USA/UK |
| ECCN | EAR99 |
| HTS-Harmonized Code (US) | 8525.50.3035 |
| TAA Compliant | No |
| UNSPSC Code | 43222827 |
| UPC Code | 195285742032 |
| What's In The Box | 1x amplifier |
| AddOn Part# | ADD-QSFP28-EDFA-PREAMP-17DB |
| Ingram Micro® | 13JP66 |
| Ingram Micro® Canada | 741C2W |
| Insight Electronics® | ADD-QSFP28-EDFA-PREAMP-17DB |
| TD Synnex CA | 7229040 |
| TD Synnex US | 7309154 |
| Tech Data® | 14865423 |
Limited Lifetime
